Feature:
• Touch part with heating are used SUS304# mirror stainless panel.
• Easy On/Off Non-Machinery 電磁式buckle without defection of Particle.
• With complete Series of HEPA FILTER Class 100 Baking Environment.
• Excellent Temperature Average.
• Temperature can reach MAX 350oC(T2 Model
• Oxidation can be lower 20ppm (with N2 Purge).
• Good design of back door to keep shape without changing or air outlet.





Specification:
Model Inner (WxDxH)(cm) Outside (W x D x H)(Cm)
1 40×45×40 97×65×92
2 65×50×60 85×99×143
3 65×50×90 85×99×178
4 80×60×100 100×110×188
5 95×60×110 115×110×200
6 120×60×100 164×88×183

Note:
1.Can choose T1(MAX 250oC) or T2(MAX 350oC).
2. Can accept model in different dimension.
OPTION:
1. LCD Display Multi-Function Controller (with RS-485 communication).
2. USE WUPA FILTER can raise the purity
3. Cooling System by Water or by Air (direct or indirect), can speed lowing down temperature.
4.PC Control (One or More sets of Oven Monitor Recording System)
5.Temperature Recorder (6 points).
6. Oxidation Indicator.


Specification:
Model Inner (WxDxH)(cm) Outside (W x D x H)(Cm)
SOL-D-8 168×65×147

235×94×220
